1.3 Inch Round TFT Display , 320x320 24 PINS MIPI 500cd/M2 Driving IC ST7796DW
| MOQ: | 1~1000 |
| Price: | $6.2~$6.0 |
| Standard Packaging: | blister+foam box+bubble bag+inside carton+master carton |
| Delivery Period: | 4~6weeks |
| Payment Method: | T/T |
| Supply Capacity: | 500K pcs per month |
Detail Information
Place of Origin
China
Brand Name
HuaXin
Certification
ISO14001/ ISO9001/IATF16949
Model Number
HX130009B0
Display Technology:
Round Tft Panel
Name:
Circular Tft Display
Display Size:
1.3 Inch Tft
Resolution:
320x320
Interface:
1 Line MIPI
Driving IC:
ST7796DW
Brightness:
500c/d
View Angle:
All
Highlight:
1.3 inch round TFT display
,320x320 MIPI TFT screen
,ST7796DW driving IC display
Product Description
1.3 Inch Round TFT Display
High-resolution 320x320 round TFT display with 24-pin MIPI interface and ST7796DW driving IC, delivering 500cd/m² brightness.
Product Specifications
| Item | Specification |
|---|---|
| Model Number | HX130009B0 |
| Size | 1.3 inch round TFT |
| LCD Type | Normally Black |
| Drive Element | TFT active matrix |
| Number of Pixels | 320*3RGB(H)X320(V) |
| Pixel Arrangement | RGB stripe |
| Pixel Pitch (W*H) | 0.1035*0.1035 |
| Active Area | 33.12(H) * 33.12(V) |
| Mechanical Outline Size (W*H*T) | 36.12*39.16*1.42 |
| Viewing Direction | Free |
| IC/LCM Driver IC | ST7796DW |
| LCM Interface | 1 Lane MIPI Interface |
| LCM Pin Count | 24 |
| Backlight LEDs Number | 2 |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -30°C to +80°C |
| Luminance | 500 cd/m² |
Product Images
Technical Drawings
TFT Display Characteristics
- Image Quality: High resolution, sharpness, and color accuracy
- Response Time: Fast pixel switching for smooth motion
- Viewing Angles: Wide angles with minimal color shift
- Energy Efficiency: Lower power consumption than alternatives
- Size Options: Available in various sizes from small to large panels
- Backlighting: LED backlighting for illumination
- Applications: Versatile usage across multiple industries
TFT Display Limitations
- Viewing angles limited compared to newer technologies
- Contrast ratio limitations
- Backlighting requirements increase power consumption
- Potential motion blur in fast-moving images
- Limited physical flexibility
- Color gamut limitations compared to some alternatives
Product Applications
- Car navigation systems and printers
- Video communication and advertising displays
- Automotive dashboards and medical devices
- Fitness equipment and handheld devices
- Industrial control systems and home appliances
Manufacturer Information
Huaxin Technology (Enshi) Co., LTD
Location: Hubei, Enshi
Founded: 2009
Specialization: Research, development, production and sales of LCD, LCM, TFT, backlight, and OLED technologies
Product Range
- LCD: VA, TN, HTN, STN, FSTN, CSTN and other series
- LCM: COB, TBA, COG, TP, LED backlight and other series
Company Advantages
- Cost-effective operations in inland China
- Advanced equipment ensuring stable quality
- Fully automated production processes
- Professional engineers with 20+ years experience
- In-house design capability for custom products
Certifications
- ISO14001
- ISO9001/IATF16949
- SGS certified LCD modules
Production Capacity
| Product Type | 2021 | 2022 Goal | 2023 Goal | 2024 Goal | 2025 Goal |
|---|---|---|---|---|---|
| LCD Production (k logs/day) | 4.5 | 9 | 9 | 9 | 9 |
| LCM Production (k pieces/day) | 70 | 150 | 300 | 450 | 450 |
| Backlight Production (k pieces/day) | 100 | 200 | 300 | 500 | 500 |
| OLED Production (k pieces/day) | 10 | 20 | 30 | 40 | 50 |
